Prime Clean Reset

Clean room doors (Prime Clean Reset) are designed for inside applications requiring limitation of leak flow. The perfect sealing properties of Prime Clean Reset provide environmental control and protect the inside environment against draughts, dust and dirt. Clean room doors provided by us also has self- repairing system.

One of the most imperative aspects of clean rooms is the Door you choose for clean room facility. Time for which door is open will play a critical factor in avoiding dirt, temperature, humidity etc. Opening and closure of door has to quick enough to isolate the two areas.

At Gandhi Automations Pvt Ltd we provide Clean Room High Speed Doors specifically designed for above purpose. Our Clean Room High Speed Doors are best suited for pharma industries where you need to have controlled environment. The opening and closing of door is fast enough to separate two areas.

  • Designed for use in dust free and clean room area
  • Low air permeability in pressurized rooms and minimizes leakage
  • Maintains air tight sealing even in differential pressure situations on either side
  • Self-supporting construction
  • Flexible curtain without any rigid elements – safe for personnel & equipment
  • High leak tightness due to the close filling curtain in the guide rails
  • Can be equipped with FDA Approved Polystone® M-Natural – slim design guide.
  • They require little space and can easily be installed in tight places.
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Clean Room Doors suppliers
Door Type Roll-up
Usage Internal
Maximum Width 4000 mm
Maximum Height 4000 mm
Opening Speed Up to 2.0 m/s
Closing Speed 0.5 m/s
Security Features CE Certified, European standards EN 13241-1
Cleanroom Class ISO Class 5
Resistance to Wind Load Up to wind load class 3 according to the European standard EN 12424
Permeability Air < 12 m3/m2h to European standard EN 12426 at 50 Pascal to European standard EN 12427
Fabric Curtain 0.9 - 1.5 mm
Transparent PVC Section 2.0 mm
Side Guide UHMWPE 1000
Guide Material / Surface Aluminium / Stainless Steel 304 / 316

Standard Specifications

  • 230V-1ph, N / 415V-3ph, N
  • Open / Stop / Close
  • Operator : IP 54 / Control : IP 65
  • Crank Handle
  • Inbuilt Photocell
  • Bottom Wireless Safety Edge System
  • Electronic

Additional Optional Accessories

  • Light Grille With IP67 Protection
  • Radar Presence Detector, Induction Loop, Magnetic Loop Detector
  • Wave Sensor / Pull Cord / Emergency-OFF Button
  • Traffic light, Flashing Light with or without Buzzer
  • Between multiple doors, equipped with a client control unit

Standard Curtain Colours Similar to

  • Blue RAL 5010
  • Yellow RAL 1018
  • Orange RAL 2004
  • Black RAL 9005
  • Red RAL 3002
  • Grey RAL 7035
  • White RAL 9003
  • Green RAL 6026

Available Vision Windows

  • Round
  • Oval
  • Rectangle
*Customised printed curtain is available on request.
